High Strength Steel Self Drilling Anchor Nut With Excellent Structural Stability

Name: High Strength Steel Self Drilling Anchor Nut With Excellent Structural Stability
Brand: Yanggu Henglong Construction Machinery Co., Ltd.
Availability: InStock

Brand Name:	HLDRILL
MOQ:	10PCS
Price:	Please contact us
Payment Terms:	T/T
Supply Ability:	2000PCS Per Month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO9001

Product Name:

Anchor Nut

Product Material:

High-strength Steel

Product Type:

Self-Drilling Anchor Nut

Structural Features:

Precise Thread, Secure Locking, Stable Structure

Performance Characteristics:

High Strength, High Tensile Strength, Not Easy To Loosen

Surface Treatment:

Corrosion And Rust Resistant, Durable

Applicable Scenarios:

Anchor Bolt Support For Tunnels, Mines, Slopes, Foundation Pits, Etc

Product Advantages:

Easy Installation, Even Force Distribution, And Improved Overall Anchoring Stability

Packaging Details:

Wooden Box

Highlight:

High Strength Steel Anchor Nut

Self Drilling Anchor Nut

Product Description

High-Strength Steel Self Drilling Anchor Nut with Excellent Structural Stability

Excellent Structural Stability for Engineering Applications

The Henglong Self-Drilling Anchor Nut is an innovative engineering reinforcement component that combines drilling, anchoring, and locking functions into a single operation. Designed for efficiency and reliability, it eliminates the need for pre-drilling or hole cleaning.

Key Features

Integrated drilling and anchoring process saves time and labor
Manufactured from high-strength steel for maximum durability
Precision-machined sides meet strict anchoring specifications
One-piece forged structure provides exceptional stability
Withstands dynamic loads, vibrations, and extreme conditions
Secures entire self-drilling anchor system at designated points

Performance Advantages

Our self-drilling anchor nuts solve common problems with traditional anchoring methods, including cumbersome procedures, low efficiency, and insecure anchoring. The design offers:

Simplified installation process
Superior load-bearing capacity
Enhanced construction efficiency
Long-term structural stability

Applications

Widely used in critical engineering projects including:

Slope reinforcement and stabilization
Foundation pit support
Tunnel reinforcement
Mine safety systems

Product Specifications

Hexagonal Nut Dimensions

Size	SW (mm)	L (mm)	Unit Weight (kg)
R25	41	41	0.3
R32	46	45	0.35
R32	46	65	0.45
R38	50	60	0.5
R51	75	70	1.55
T76	100	80	2.8

Spherical Nut Dimensions

Size	SW (mm)	L (mm)	Unit Weight (kg)
R32	46	45	0.45
R38	50	50	0.6
R51	75	70	1.6
T76	100	90	3.2
T30	46	35	0.42
T40	65	50	0.9
T52	80	70	2.2
T73	95	70	2.2
T103	125	80	3.4
T127	140	140	9.2
